1/ Elevating Technical Education with the QME-KN012 Trainer

The Electro-Pneumatic Training System QME-KN012 is a cutting-edge educational platform designed and manufactured in compliance with ISO 9001:2015 quality standards. The system features a standardized modular design, allowing students to flexibly assemble components during practical exercises and enabling seamless future upgrades.

2/ Premium Industrial Configuration with SMC & FESTO Components

To provide hands-on experience that mirrors real-world factory environments, all pneumatic components integrated into the QME-KN012 training rig are sourced from global leaders SMC and FESTO. The system includes:

• Diverse Actuators: Features single-acting cylinders, double-acting cylinders (100mm stroke), and loaded cylinders. These cylinders come with built-in magnetic rings for seamless integration with position sensors.
• Industrial Solenoid Valves: Fully equipped with 3/2 normally closed solenoid valves (single/double coil), 5/2 valves, 5/3 closed-center valves, and a high-performance Festo proportional pneumatic control valve (1400 l/min nominal flow).
• Specialized Air Supply: Powered by a heavy-duty 7.5 HP Puma air compressor with a 280L tank. Designed specifically for laboratory use, it operates with very low noise levels; one compressor can simultaneously supply two QME-KN012 training units.

3/ Practical PLC & Electro-Pneumatic Training Curriculum

The QME-KN012 pneumatic training equipment bridges the gap between theory and industrial application. Students will gain practical skills in:

• Reading circuit diagrams, operating 3/2 and 5/2 valves, and controlling cylinders based on electrical signal feedback from sensors.
• Programming PLC-controlled electro-pneumatic systems, including single-run conditions, continuous operation, and emergency stops.
• Wiring and simulating real-world industrial mechanisms, such as bench drills, filling equipment, stamping devices, embossing machines, clamping mechanisms (vises), and part separation mechanisms.

4/ Contact for Technical Consultation & Project Solutions

We understand that every educational institution has unique infrastructural requirements. QME provides tailored technical consultations and customized project proposals to perfectly match your facility's needs. To upgrade your engineering lab with the Electro-Pneumatic Training System QME-KN012, please contact our engineering team:
